Partes Grua de Rescate Versión en línea Aprenderá a Identificar los componentes y partes de la Grúa de Rescate P/N 42305-3/-5. por Taller Equipos Especiales 1 Winch Assembly 2 Boom Head Assembly 3 Boom Position Support Assembly 4 Hoist Controller Assembly 5 Control Pendant Assembly 6 Cable extension indicator 7 Hoist up/down thumbwheel 8 Boom Out/In switch 9 Intercomunication switch (ICS) 10 Caution/Overtemp Lamps 11 Winch Housing 12 Limit switch drive assembly 13 Electric motor 14 Inertia dump assembly 15 Storage drum 16 Cable Assembly 17 Electrical Harness Assembly 18 Cable Cutter 19 Boom Assembly 20 Sheave Assembly 21 Pressure Roller Cover 22 Pressure Roller assembly 23 Reaction Arm 24 Switch Cover Assembly 25 Stanchion tube with internal boom motor, Rotary actuator, Gear Drive, And Mechanical Stop Assemblies 26 Cooling Fan 27 Hour Meter 28 Boom Drive Electrical Harness 29 Height Adjuster Assembly 30 Upper Support Assembly 31 Lower Support Assembly 32 Lamp (R1) (Nvg Dimming) 33 Press To Test (S2) 34 Limit Switch Receptacle (J4) 35 Power Receptacle (J1) 36 Boom Receptacle (J5) 37 Motor Receptacle (J3) 38 Up Limit Receptacle (J6) 39 Cable Cut Switch (S3) 40 Aircraft Position Switch (S1) 41 Pendant Receptacle (J2) 42 D-Lok Hook Assembly
